A pneumatic seat impact tester that checks the impact effect on the seat surface of moulded plastic chairs — an 18 kg weight is driven onto the seat by a pneumatic cylinder, with a counter to log the number of trials.
Moulded plastic chairs must withstand repeated sitting impact without cracking at the seat. A seat impact tester delivers a controlled, repeatable impact to the seat surface and counts the number of trials, so manufacturers can verify a design and its resin and wall thickness.
International Equipments builds a pneumatic seat impact tester: a 400 mm-stroke, 40 mm-diameter cylinder with a solenoid valve drives an 18 kg weight onto the seat, guided by four 2.0 m hard-chrome shafts, with a height-adjustable frame and a trial counter. A 5–10 kg/cm² compressor is arranged by the customer. Manufactured in Mumbai.
Representative specifications; a 5–10 kg/cm² compressor is arranged by the customer.
| Function | Impact on the seat surface of plastic moulded chairs |
|---|---|
| Pneumatic cylinder | 400 mm stroke, 40 mm diameter, with solenoid valve |
| Impact weight | 18 kg |
| Counter | Counts the number of trials |
| Guide shafts | Four hard chrome plated, 2.0 m height |
| Height | Adjustable (lockable) |
| Compressor | 5–10 kg/cm² (arranged by customer) |
| Power | 230 V, 50 Hz, single phase |
Send your material, test standard and throughput. We'll respond within one business day with a configuration and quote.
