A pneumatic back punch impact tester that checks the impact effect on the back of moulded plastic chairs — a 3.2 kg weight is driven onto the chair back by a pneumatic cylinder, with a trial counter.
Where the Seat Impact Tester loads the seat surface, the back of a moulded chair sees a different, lighter impact from occupants leaning back. This tester delivers a controlled, repeatable impact to the chair back and counts the trials, so manufacturers can verify design and wall thickness.
International Equipments builds a pneumatic back punch impact tester: a 300 mm-stroke, 40 mm-diameter cylinder with a solenoid valve drives a 3.2 kg weight onto the chair back, guided by four 1.5 m hard-chrome shafts, with a height-adjustable frame and a trial counter. A 5–10 kg/cm² compressor is arranged by the customer. Manufactured in Mumbai.
Representative specifications; a 5–10 kg/cm² compressor is arranged by the customer.
| Function | Impact on the back of plastic moulded chairs |
|---|---|
| Pneumatic cylinder | 300 mm stroke, 40 mm diameter, with solenoid valve |
| Impact weight | 3.2 kg |
| Counter | Counts the number of trials |
| Guide shafts | Four hard chrome plated, 1.5 m height |
| Height | Adjustable (lockable) |
| Compressor | 5–10 kg/cm² (arranged by customer) |
| Power | 230 V, 50 Hz, single phase |
Send your material, test standard and throughput. We'll respond within one business day with a configuration and quote.
