A laboratory heat sealer to determine the suitable sealing parameters of films — with two temperature zones, a pneumatically operated sealing jaw and controlled dwell, so you can map the optimum sealing window.
Seal quality is governed by temperature, pressure and dwell time. A laboratory heat sealer makes controlled seals across a range of these settings so the optimum sealing window can be mapped; the seals are then peeled on a tensile or peel tester to measure seal strength.
International Equipments builds a heat sealer with two independently controlled temperature zones (auto-tuned PID up to 200 °C), a pneumatically operated sealing jaw and a 150 × 20 mm seal area, to determine the suitable sealing parameters of films. Table-top, manufactured in Mumbai, CE marked and calibration-certified.
Representative specifications; configuration on request.
| Purpose | Determine suitable sealing parameters of films |
|---|---|
| Temperature zones | Two |
| Controller | Auto-tuned PID, up to 200 °C, resolution 0.1 °C |
| Clamping jaws | One fixed, one movable by pneumatic action |
| Speed | 300 mm/minute |
| Daylight | 50 mm |
| Sealing dimensions | 150 mm (L) × 20 mm (W) |
| Mounting | Table top |
| Power | 230 V, 60 Hz, single phase, 15 A |
Send your material, test standard and throughput. We'll respond within one business day with a configuration and quote.
Request a Quote
